1. Products Description of MCLLROY Wheel Loader
We need the construction machine to do heavy work, obviously it has to be efficient, take loader as an example, the bucket should shovel as much as possible, the loader should be stable while working, the control should be flexible and easy, the malfunction rate is low of course.
MCLLROY wheel Loader is a kind of front wheel loader with single bucket ,articulated and hydraulic unloading. It has been developed and designed in accordance with user requirements, reference models after absorption of domestic and overseas advanced similar structural features and advanced technology.
2. Specification of MCLLROY Wheel Loader
| MSL918D/ZL918D | Metric Units |
| Engine Model | Changfa 490 /Yun Nei 490 |
| RPM | 2400 |
| Rated Power | 42 kW |
| Emissions | EU Stage II |
| Operating Weight | 2500 kg |
| Rated Load | 800-1000 kg |
| Bucket Capacities | 0.5 m³ |
| Max. Travel Speed | 28 km/h |
| Gear Box | CVT
265 torque converter |
| Axle | Small hub |
| Axle Base | 2100 mm |
| Brake | Air Brake |
| Hydraulic Cycle time - lift | ≤ 9 s |
| Min. Ground Clearance | 230 mm |
| Wheel Base | 1650 mm |
| Reach at Max.Dump Height | 2900 mm |
| Dump Reach | 870 mm |
| Overall Length - With Bucket | 4700 mm |
3.Details and advantages of MCLLROY Wheel Loader
The EXT automatic inflating system provides operator a freely inflation job.
The fuel tank is equipped with loose-leaf , easily accessible service points make daily checks fast and effective.
Service brake control adopts the double-booster pump air over caliper disc brake, which has the characteristics of great brake power, convenient dismantling, safety and reliability.
4. Inspection of MCLLROY Wheel Loader
The inspection is as important as any other procedure. MCLLROY technicians usually need to inspect the followings (Part I):
1) Adjust the tire pressure, drive the loader to the inspection platform, to see if the bucket is level to the ground when it is on the ground.
2) Check if the hydraulic oil is enough, and then lift the arm, withdraw the bucket and check the hydraulic oil level again, check the hydraulic oil tank scale (scale at 11 to 13 means enough)
3) Check if any bolts are loose or missing, and if there is a oil leaking problem.
4) Check the track width to see if it is different from standard.
